Line Cars (hydraulic Driven)

Line Cars (hydraulic Driven)

(2, 3, 4 conductors for tower surpassing with drive unit)

The Line Cars LCA-01-xx are powered by a 6.3 KW Honda gasoline engine which drives a hydraulic pump and motors on two axles. Without being pulled by external force they are capable to travel along conductor spans and climb slopes up to 25 % inclination. The maximum travelling speed are 40m/min. The hydraulic system serves also as a very effective dynamic brake. Like all our other linecars the LCA-01-xx are equipped with parking brake and a meter counter.



It is equipped with 4 openable axles and a jack for closing them, the LCA-01-xx is capable to surpass over suspension towers.

part no. ZECK GmbH
part no.
description SWL
Kg
spacing between
conductors mm
dimensions
LxWxH (mm)
weight
Kg
LCA-02-02 77-6130 2-bundles 200 400-600 2100x1200x1800 215
LCA-02-03 77-6131 3-bundles 200 400-600 2100x1200x1800 220
LCA-02-04 77-6132 4 bundles 200 400-600 2100x1200x1800 225



Optional Equipment:

part no. ZECK GmbH
part no.
description safe lifting load
Kg
weight
Kg
LCP-00-01 77-6129 meter counter - 1.25
LCP-00-02 947-800 lifitng device 500 9
